135VXR-7000 UHF Service Manual

SW Unit (25W Type)

Circuit Diagram

Parts Layout

PCB with Components CB1647002

JP6501 WIRE ASSY A1367+ T9206794 1-

JP6502 WIRE ASSY WHT 340 SRA/<7> T9318166 1-

JP6503 WIRE ASSY BLK 330 SRA/<7> T9318167 1-

JP6504 WIRE ASSY BRN 320 SRA/<7> T9318168 1-

JP6505 WIRE ASSY GRA 330 SRA/<7> T9318169 1-

S 6501 PUSH SWITCH SDDFE30100 N4090147 1-

Parts List

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR

Side A

Side B
