134 VXR-7000 UHF Service Manual
Filter-2 Unit (25W Type)
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
R 6012 CEMENT RES. 5.6 5W 5% BWR5C5R6J J30375569 119- A H2
R 6013 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A D3
R 6023 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- A E3
R 6024 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A E3
R 6025 CHIP RES. 180 1/16W 5% RMC1/16 181JATP J24185181 1- A E4
R 6026 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A E3
R 6027 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A E3
R 6028 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E4
R 6029 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A E4
R 6030 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A E4
R 6031 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A E4
RL6001 RELAY DC12V ACP131 DC12V M1190152 1- A D2
RL6003 RELAY DC12V ACP131 DC12V M1190152 1- A D3
T 6001 TOROIDAL COIL D12A RI16X8X8 L0022119 1- A B4
T 6003 TOROIDAL COIL D12A RI16X8X8 L0022119 1- A B3
RUBBER RA0217100 16-
