Vertex Standard VXR-7000 Service Manual

127VXR-7000 UHF Service Manual
PCB with Components
(
w/o F6001 & F6002
)
CS1682002
C 6002 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A A4
C 6002 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A A4
C 6003 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A B4
C 6003 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A B4
C 6004 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A C4
C 6006 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A C2
C 6007 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A B2
C 6007 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A B2
C 6008 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A D4
C 6008 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A D4
C 6009 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A D4
C 6009 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A D4
C 6010 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A F4
C 6011 CHIP CAP. 0.01uF 50V B GRM216B11H103KA01D K22170817 1- A F4
C 6012 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A E4
C 6013 AL.ELECTRO.CAP. 100uF 25V RJ3-25V101MF3#-T2 K46140010 1- A E3
C 6014 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 58- A E4
C 6015 CHIP CAP. 470pF 50V B GRM188B11H471KA01D K22174805 1- A E3
C 6016 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A E3
C 6020 CHIP CAP. 0.01uF 50V B GRM216B11H103KA01D K22170817 1- A D4
D 6001 DIODE 1SS355 TE-17 G2070470 1- A E5
D 6002 DIODE DAN202K T146 G2070182 1- A D2
D 6004 DIODE DSA3A1 G2090445 1- A F3
D 6005 DIODE DAN202K T146 G2070182 1- A D4
D 6006 DIODE 1SS355 TE-17 G2070470 1- A D4
D 6007 DIODE 1SS355 TE-17 G2070470 1- A D4
D 6008 DIODE 1SS355 TE-17 G2070470 1- A E3
F 6001 FUSE 5A MF60NR250V 5A Q0000005 1-94 A F2
F 6001 FUSE 5A 61NR050H 250V 5A Q0000157 95- A F2
F 6002 FUSE 20A AF20A 20A Q0000079 1-111
F 6002 FUSE 20A JASO020 20A Q0000154 112-
FH6001 FUSE CLIP S-N5051#01 P2000059 1- A I4
FH6002 FUSE CLIP S-N5051#01 P2000059 1- A F4
J 6001 TERMINAL Y106 S5000179 1- A F1
J 6002 TERMINAL Y106 S5000179 1- A G2
J 6003 TERMINAL Y106 S5000179 1- A A3
J 6004 TERMINAL Y106 S5000179 1- A A4
J 6005 TERMINAL Y106 S5000179 1- A J2
J 6006 TERMINAL Y106 S5000179 1- A J2
J 6007 TERMINAL Y106 S5000179 1- A I1
J 6008 TERMINAL Y106 S5000179 1- A I2
J 6009 TERMINAL Y106 S5000179 1- A J4
J 6010 TERMINAL Y106 S5000179 1- A H2
J 6011 CONNECTOR SC25-02WS P0090621 1- A D4
J 6012 CONNECTOR B2B-EH(LF)(SN) P0090666 1- A E5
J 6014 TERMINAL Y106 S5000179 1- A F4
J 6015 TERMINAL Y106 S5000179 1- A G4
JP6001 WIRE ASSY A1367+ T9206789 1- A D5
Q 6001 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- A E3
Q 6002 TRANSISTOR UN5213-(TX) G3070192 1-157 A E2
Q 6002 TRANSISTOR UN5213-(TX) G3070440 158- A E2
Q 6003 TRANSISTOR XN1213-(TX) G3070194 1-167 A E5
Q 6003 TRANSISTOR DMC261030L G3070445 168- A E5
Q 6004 TRANSISTOR 2SC2812L6-TA G3328127F 1-6 A E2
Q 6004 TRANSISTOR 2SC2812N6-CPA-TB-E G3328128F 7-182 A E2
Q 6004 TRANSISTOR MMBT6428LT1G G3070500 183- A E2
Q 6006 IC NJM2904M-TE2 G1093091 1- A D4
Q 6007 TRANSISTOR IMX1 T110 G3070024 1- A E4
Q 6008 TRANSISTOR 2SC2812L6-TA G3328127F 1-6 A E4
Q 6008 TRANSISTOR 2SC2812N6-CPA-TB-E G3328128F 7-182 A E4
Q 6008 TRANSISTOR MMBT6428LT1G G3070500 183- A E4
R 6001 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A E3
R 6002 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A E3
R 6003 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A E3
R 6004 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E2
R 6005 CHIP RES. 22 1/10W 5% RMC1/10T 220J J24205220 1- A D2
Filter Unit (50W Type)
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
