131VXR-7000 UHF Service Manual

Parts Layout (Side A)

A B C D

E GFH

DAN202K (N)

(D6002, 6005)

2SA1179 (M6)

(Q6001)

2SC2812 (L6)

(Q6004, 6008)

UN5213 (8C)

(Q6002)

XN1213 (9L)

(Q6003)

IMX1 (X1)

(Q6007)

Filter-2 Unit (25W Type)

I KJ
