Vertex Standard VXR-7000 Service Manual

84 VXR-7000 UHF Service Manual
RX-2 Unit (Lot.60-)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
D 3006 DIODE HVU350 TRF-E G2070380 1- A B3
D 3007 DIODE HVU350 TRF-E G2070380 1- A E2
D 3008 DIODE HVU350 TRF-E G2070380 1- A B3
D 3009 DIODE HVU350 TRF-E G2070380 1- A B3
D 3011 IC GN2011-Q(TX) G1092183 1-74 A C2
D 3011 IC GN2011-P(TX) G1094261 75-89 A C2
D 3011 IC SPM5001-TL-E G1093686 90-133 AC2
D 3011 IC SPM5002-TL-E G1094899 134- A C2
D 3012 DIODE MA142WK-(TX) G2070534 1-146 B b3
D 3012 DIODE DA3J103E0L G2071346 147- B b3
D 3013 DIODE MA142WK-(TX) G2070534 1-146 B b3
D 3013 DIODE DA3J103E0L G2071346 147- B b3
D 3014 DIODE HZM5.6NB2 TR-E G2070722 1- B c3
D 3015 DIODE MA143-(TX) G2070536 1-185 A E2
D 3015 DIODE DA3J101F0L G2071354 186- A E2
D 3016 DIODE MA143-(TX) G2070536 1-185 A E2
D 3016 DIODE DA3J101F0L G2071354 186- A E2
D 3019 DIODE HVU350 TRF-E G2070380 1- A D2
D 3020 DIODE HVU350 TRF-E G2070380 1- A D2
J 3001 CONNECTOR TMP-J01X-V6 P1090210 1- A C1
JP3001 WIRE ASSY A1367+ T9206791 1- A A3
JP3002 WIRE ASSY A1367+ T9206788 1- A F1
L 3001 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A F1
L 3002 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A E1
L 3002 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A E1
L 3002 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A E1
L 3003 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B3
L 3004 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A E1
L 3004 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A E1
L 3004 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A E1
L 3005 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B3
L 3006 M.RFC 0.015uH LL1608-F15NK L1690361 1- A E1
L 3007 COIL E2 0.5-2.0-7T-R L0022489 VERS. A 1- A B3
L 3007 COIL E2 0.5-2.0-7T-R L0022489 VERS. BS1 62- A B3
L 3007 COIL E2 0.5-2.0-6T-R L0022488 VERS. D 1- A B3
L 3008 CHIP COIL 0.017uH LQW31HN17NJ03L L1690249 1- A E1
L 3009 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B2
L 3010 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A D1
L 3010 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A D1
L 3010 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A D1
L 3011 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A C2
L 3012 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A D1
L 3012 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A D1
L 3012 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A D1
L 3013 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B2
L 3014 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A D1
L 3014 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A D1
L 3014 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A D1
L 3015 CHIP COIL 0.022uH C2520C-22NK L1690536 1- A B2
L 3016 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 1- A D1
L 3016 COIL E2 0.3-1.4-5T-L L0022882 VERS. BS1 62- A D1
L 3016 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 1- A D1
L 3018 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- A C1
L 3019 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- A C1
L 3021 M.RFC 0.33uH LK2125 R33K-T L1690313 1- A E3
L 3022 M.RFC 10uH LK2125 100K-T L1690331 1- B d3
L 3023 CHIP COIL 0.22uH C2520C-R22J L1690548 1- A C3
L 3024 M.RFC 0.1uH LK2125 R10K-T L1690307 1- A D3
L 3025 M.RFC 1uH 5% C2012C-1R0J L1691160 1- A D3
L 3028 CHIP COIL 0.68uH C2520C-R68J L1690554 1- A D3
L 3029 M.RFC 4.7uH LK1608 4R7K-T L1690688 1- A A2
Q 3001 IC MB15A02PFV1-G-BND-EFE1 G1092541 1- A A2
Q 3002 IC TAR5S30(TE85L.F) G1093570 1- A A2
Q 3003 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A A1
Q 3004 TRANSISTOR UN5215-(TX) G3070193 1-152 A A1
Q 3004 TRANSISTOR DRC5114T0L G3070444 153- A A1
Q 3005 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A E1
