86 VXR-7000 UHF Service Manual
RX-2 Unit (Lot.60-)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE
LAYADR
Parts List
R 3057 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b3
R 3058 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B a3
R 3060 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A C3
R 3061 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- B b3
R 3062 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a2
R 3063 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- B b2
R 3064 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B b3
R 3065 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
R 3066 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B b3
R 3067 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- B b2
R 3068 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a2
R 3069 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A D3
R 3071 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A E2
R 3072 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A E2
R 3074 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 3075 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A E2
R 3076 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E2
R 3077 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B c3
R 3078 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D2
R 3079 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B c3
R 3080 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A E2
R 3081 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A E2
R 3082 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B a2
R 3083 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3084 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3085 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A D3
R 3086 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A E2
R 3087 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A D3
R 3088 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3089 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 3105 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D2
R 3106 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D2
R 3108 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A B1
T 3001 COIL WIDE-TRANS. 3-317611 L0022478 1- A C2
T 3002 COIL WIDE-TRANS. 050812563 92H5 L0022479 1- A C2
T 3003 COIL WIDE-TRANS. 3-317611 L0022478 1- A C2
X 3001 XTAL OSC 14.4MHz TTS12V 14.4MHZ H9500650 1- A A2
X 3002 XTAL TOP-B 72.895MHz 72.895MHZ H0103161A 1- A E3
XF3001 XTAL FILTER TM7050A MF73P H1102363 1-61 A C3
XF3001 XTAL FILTER TM7050A MF73P2 H1102381 62- A C3
XF3002 XTAL FILTER TM7050A MF73P H1102363 1-61 A D3
XF3002 XTAL FILTER TM7050A MF73P H1102363 62- A D3
SHIELD CASE CASE-S7GDH L9190016 1-184
SHIELD CASE KC-175 L9190207 185-
SHIELD CASE CASE-S7GDH L9190016 1-184
SHIELD CASE KC-175 L9190207 185-
SHIELD CASE CASE-S7GDH L9190016
VERS. A (EIA/CE)
1-184
SHIELD CASE KC-175 L9190207
VERS. A (EIA/CE)
185-
SHIELD CASE CASE-S7GDH L9190016
VERS. D (EIA/CE)
71-184
SHIELD CASE KC-175 L9190207
VERS. D (EIA/CE)
185-
SHIELD CASE CASE-S7GDH L9190016
VERS. BS1 (EIA/CE)
62-184
SHIELD CASE KC-175 L9190207
VERS. BS1 (EIA/CE)
185-
SHIELD CASE CASE-S7GDH L9190016
VERS. BS1 (ex. EIA/CE)
62-184
SHIELD CASE KC-175 L9190207
VERS. BS1 (ex. EIA/CE)
185-
SHIELD CASE RA0014300 1-
SHIELD CASE VCO R0151950 1-
SHIELD CASE RA0014200 1-
NYLON CLAMP PLT-1M BK-1 S3000022 1-
LEAF SPRING R0140031 1-
LEAF SPRING R0140031 1-
To Next Page
