Diagnostics HD-98 Door Operator with OST
24 Vertical Express
E14 0-70 25 Manual Closing Speed - This adjusts door speed after deceleration until travel-in distance
is reached. When travel-in distance is reached, the doors will then run 3/4 manual speed
to the door close limit. This is also the speed the doors will travel if the manual close but-
ton is pressed on the door operator card. Manual closing speed will be increased as this
adjustment value is increased.
E15 1-8 4 Close Acceleration to High Speed - This adjusts the rate the doors accelerate to close high
speed. The acceleration rate will be increased as this adjustment value is increased
E16 0-2000 110 Close Slowdown Distance - This adjusts the point the doors begin decelerating to manual
close speed. Slowdown distance should be large enough to allow manual close speed to
be reached prior to reaching the door close limit. Close slowdown distance will be
increased as this adjustment value is increased.
E17 0-1 0 Reduced Torque On Stall -This adjustment can be used to cause the door torque to be
reduced when the doors are stalled. Door torque will be increased as this adjustment
value is increased.
E18 0-255 34 Close Travel-In Distance - This adjusts the distance the doors travel at 3/4 manual close
speed into the door close limit. This occurs after deceleration has reduced the door speed
to manual speed. This is also the point where the door torque is increased for stalled
doors on the 5th and 6th cycles. The close travel-in distance will be increased as this
adjustment value is increased.
E19 0-100 40 High Speed Clamp - This sets the maximum speed (from motor rpm) the doors will be
allowed to travel (open or close) before the doors are stopped. When the clamp is acti-
vated, the doors are momentarily stopped and then allowed to run again with constant
over-speed protection. When this clamp stops the doors, a door fault will be set to inform
of the overspeed (326 open, 327 closed). The High Speed Clamp speed will be increased
as this adjustment value is in- creased.
E20 1-255 41 Closing Door Torque - This adjusts the static closing force in the center third of door
travel. Door torque will be increased as this adjustment value is increased.
E21 1-60 20 Nudging Duty - This adjusts the closing speed when the doors are on nudging operation,
or safety edge or photo eye failure. Nudging speed will be increased as this adjustment
value is increased.
E22 0-255 130 Six Inch From Closed - Position count for the 6-inch from close point.
E23 0-1 0 Continuous Door Cycle - When set to 1, causes the door to cycle continuously. Set to 0,
the door works in normal operation.
E24 0-1 0 Manual Door Cycle - When set to 1, causes the door to run at manual speed opening and
closing. Set to 0, the door runs at normal speed.
E56 0-1921 0 Travel - This adjustment is the number of pulse counts between DOL (door open limit) and
DCL (door close limit). This count is automatically set on power-up when the saved value
in the CPU memory is zero. The doors will begin the set-up count from DOL. If the doors
are not on DOL, they will move to DOL and then close, counting pulses until their arrival at
DCL.
Adjustment Range Default Definition
