Basic Rack PDU User Manual
Chapter 1 Introduction
This chapter includes a brief overview of the functions, specifications, models and specifications of the Basic PDU
(referred as PDU) in the VERTIV™ GEIST™ rack PDU.
1.1 Functions
Basic PDU is pow er distribution unit that provides a safe and reliable pow er supply for all critical IT equipment
w ithin a rack or cabinet. It is suitable for facilities equipped with surge protection at the main electrical service
entrance. The unique U-Lock structure of Geist PDU (applicable to select SKUs) ensures the locking of the socket
and improves the reliability of equipment power supply. Color grouping of U-lock can effectively improve the
management efficiency of the equipment for data center managers, and different chassis colors are available for
selection (subject to availability).
1.2 Technical Specification
Environmental and Electrical specification as shown in Table 1-1
Table 1-1 PDU Technical Specification
Parameter Type
Parameter Name
Description
Environmental Conditions
Operating ambient temperature
-10 ℃ ～ 45 ℃
Storage temperature
-40 ℃ ～ 70 ℃
Operating humidity
5% ～ 95%
Storage humidity
5% ～ 95%
Operating Altitude
≤ 3050 m
Electrical parameter
Voltage
100Vac ～ 240Vac
Frequency
50 Hz/60 Hz
Compliances as show n in Table 1-2
Table 1-2 PDU Certificates Specification
Product
Certificates Type
CE
China RoHS
PDU


Receptacle types and ratings as shown in Table 1-3
Table 1-3 Receptacle Types and Rating
No.
Specifications
Appearance
Maximum load current (AC)
1
IEC C13
10 A
2
IEC C19
16 A
