Chapter 3 U-Lock
This chapter introduces the function of unique colored U-lock of Geist PDU. This feature is applicable to select
SKUs only.
3.1 Operation of U-Lock
The plug w ill be locked by the unique U-lock design w hen inserted in the socket, w ithout any additional action.
When the plug needs to be unplugged, press the U-lock bezel on the socket at tw o opposite sides to release the
lock and pull out the plug. The operation is show n in Figure 3-1.
Figure 3-1 Operation of U-Lock
Power Cable
Secured by U-Lock
Power Bezel to
Release Cable
