Circuit R410A (lbs.) Additional POE Oil (oz.)
1 88.5 50
2 88.5 50
3 88.5 50
4 88.5 50
Table 8.1 DP400 Refrigerant Charge
Requirements
Circuit R410A (lbs.) Additional POE Oil (oz.)
1 88.5 50
2 88.5 50
3 88.5 50
4 88.5 50
Table 8.2 DP500 Refrigerant Charge
Requirements
8.5.11 Additional Oil Requirements for Scroll and Digital Scroll Compressors
NOTICE
Risk of improper compressor lubrication. Can cause compressor and refrigerant system damage. Failure to use
oil types, viscosities and quantities recommended by the compressor manufacturer may reduce compressor
life and void the compressor warranty. See Evacuation, Leak Testing, and Charging on the next pagebelow for
the recommended oil for the system.
• Do not mix polyolestor (POE) and mineral-based oils.
• Do not mix oils of different viscosities.
• Consult your Vertiv sales representative, visit https://www.Vertiv.com/en-us/support/, or contact the
compressor manufacturer if questions arise.
Compressor Type Oil Type
Copeland Scroll and Digital Scroll POE Oil ISO 32 Centistroke Viscosity
1
1
Use Copeland POE Oil ULTRA 32-3MAF or other Copeland approved oils. DPN003950, Rev. 5.
Table 8.3 Compressor Type and Oil Type
See Refrigerant Charge Requirements for Air Cooled Systems on the previous page
After the system has been fully charged with refrigerant, use a hand pump to add the additional oil at the suction side of the
system while the system is running.
The amount of oil added by field service must be recorded on the tag marked "Oil Added Field Service Record" that is
attached to each compressor. The date of oil addition must also be included.
