2 NOMENCLATURE AND COMPONENTS
This section describes the configuration number for Liebert® DSE Packaged Solution 400 kW/500 kW unit and components.
2.1 Liebert DSE Packaged Solution Model Number Nomenclature
The following tables describe each digit of the 40-digit Liebert® DSE™ Packaged Solution.
DSE 400 kW/500 kW Packaged Solution Configuration Number Digits 1 to 10 Example
1 2 3 4 5 6 7 8 9 10
D P 4 0 0 T P 2 A T
Table 2.1 DSE 400 kW/500 kW Packaged Solution Configuration Number Digits 1 to 10 Example
DSE 400 kW/500 kW Packaged Solution Configuration Number Digits 11 to 36 Example
11 12 13 14 15 16 17 18 19 20 21 22 23 24 25–36
0 H 0 8 1 6 L 0 U 0 P A A P —
Table 2.2 DSE 400 kW/500 kW Packaged Solution Configuration Number Digits 11 to 36 Example
DSE 400 kW/500 kW Packaged Solution Configuration Number 37 to 40 Example
37 38 39 40
— — — —
Digit Description
Digits 1 and 2 = Product Family
DP = Liebert® DSE Packaged Solution
Digit 3to5 = Cooling Capacity, kW
400 = Nominal sensible capacity, 400-kW
500 = Nominal sensible capacity, 500-kW
Digit 6 = Air Discharge
F = Perimeter, front inlet/front supply
R = Roof-top, bottom inlet/bottom supply
B = Roof-top draw-thru, bottom inlet/bottom supply
Digit 7 = System Type
P = Air-cooled, Econ-O-Phase
Table 2.3 DSE Packaged Solution Model Number Digit Definitions
