TITLE
DATE (LATEST REV.)
REVISION
DRAWN BY:
DESIGNED BY:
APPROVED BY:
SHEET NO.
ECN NO.
REF DWG.
DWG. NO.
TM
1050 DEARBORN DR
P.O. BOX 29186
COLUMBUS, OH 43229
ES1-19-S0031 OF 1
J. HERRING
J. HERRING
J. SHIPMAN
2
06/09/2017
CABLE LAYOUT
DC SOURCE
UPS WITH MATCHING BATTERY CABINETS
LIEBERT EXL S1
MATCHING BATTERY
CABINET #1
MATCHING BATTERY
CABINET #N
LIEBERT EXL S1 UPS
TB1154:1-4
CG #1 CG #1
NOTES
1. ALL CABLE GROUPS SHOULD BE RUN SEPARATELY
TO HELP PREVENT SIGNAL INTERFERENCE.
2. IF MATCHING BATTERY CABINETS ARE A
STANDALONE SYSTEM CG #1 MUST ONLY BE RUN TO
MATCHING BATTERY CABINET #1.
