3.7 Configuring Ground Connections 29
3.7.1 Three-wire Input Connections 29
3.7.2 Recommended Grounding Configuration, Battery Systems 31
3.7.3 High-Resistance Ground Systems 32
3.8 Distributed Static Switch (1+N) System Cabling Layouts 32
3.9 Top Entry Low-Voltage 33
3.10 Bottom Entry Low-Voltage 33
4 Optional Equipment 35
4.1 Options 35
4.2 Rectifier Feed Breaker (RFB) 36
4.2.1 Remote Back-feed Breaker 36
4.3 Multi-Module System Options and Accessories 37
4.3.1 Paralleling Cable Kit 38
4.3.2 Multi-Bus Synch Module (MBSM) 38
5 Specifications 39
Appendices 53
Appendix A: Technical Illustrations 53
Vertiv | EXL S1™ Installer Guide | iv
