Figure 10.1 Premium Efficiency Fan Control Board
Item Description
1 LED indicates signal is present when lit.
2 LED indicates signal is present when lit.
3 LED indicates signal is present when lit.
Figure 10.2 Control Board HMI
Vertiv | Liebert® MC Installer/User Guide
46
