2 NOMENCLATURE AND COMPONENTS
This section describes the model number for Liebert® MC units and components.
2.1 Liebert® MC Model Number Nomenclature
Table 2.2 below describes each digit of the 25 digitconfigurationnumber. The 14 digit model number consists of the first
10 digits and last four digits of the configuration number.
Model # Part 1 Model Details Model # Part 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
M C M 0 4 0 E 1 A D 0 A 0 V U 0 0 0 0 0 0 * * * *
Table 2.1 Liebert® MC 25 Digit Configuration Number Example
Digit Description
Digits 1 and 2 = Unit Family
MC = Micro-channel Condenser
Digit 3 Platform Size
S = Small
M = Medium
L = Large
Digits 4-6 - Nominal Capacity, kW
028, 040, 055, 056, 080, 110, 160, 165, 220
Example: 040 = 40kW @ 95°F(35°C) & 27°R (15°K) ITD
Digit 7 - Control/Fan Type
E = Premium control and EC fan
Digit 8 - Refrigerant Circuits/System Refrigerant Type
1 = Single refrigerant circuit, R-410A
2 = Dual refrigerant circuit, R-410A
7 = Single refrigerant circuit, R-407C, R-22
8 = Dual refrigerant circuit, R-407C, R-22
Digit 9 - Power Supply
A = 460V / 3ph / 60Hz
B = 575V / 3ph / 60Hz
Y = 208/230V / 3ph / 50Hz
2 = 380V / 3ph / 60Hz
Table 2.2 MC Model Number Digit Definitions
