Model
MT036HE/PFD037 MT048HE/PFD054 MT060HE, PFD067, PFDZ67
Refrigerant System
Charge per Circuit,
lb (kg) *
Additional Oil Required Per Circuit, oz (ml)
<40 (18.1) 0 0 0
40 (18.1) 4 (120) 4 (120) 6 (180)
50 (22.7) 6 (180) 6 (180) 9 (270)
60 (27.2) 8 (240) 8 (240) 12 (350)
70 (31.8) 10 (300) 10 (300) 15 (440)
80 (36.3) 12 (350) 12 (350) 18 (530)
* System Charge = indoor unit + condensing unit + refrigerant lines.
For system charges over 80lb. (36.3 kg), consult your Vertiv representative.
Source: DPN003950 Rev 5.
Table 4.7 Additional oil required per refrigerant charge
Compressor Type Oil Type
Copeland Scroll and Digital Scroll POE Oil - ISO 32 Centistoke Viscosity
1
1. Use Copeland POE Oil ULTRA 32-3MAF or other Copeland-approved oils.
Source: DPN003950. Rev. 5
Table 4.8 Compressor oil types for R-410A Refrigerant
4 Piping and Refrigerant Requirements 19
