Digit and Description
Digit 13 = Reheat
0 = No reheat
2 = Electric reheat
5 = SCR reheat (048 and 060 models only)
Digit 14 = Coil, Valve, Pressure
0 = Split-system evaporator
Digit 15 = High-voltage options
D = Non-locking disconnect, 5k SCCR (048 and 060 models only)
L = Locking disconnect, 5kA SCCR (036 model only)
M = Locking disconnect, 65k SCCR (048 and 060 models only)
Digit 16 = Low-voltage options
0 = None
L = Low-voltage terminalpackage (LVTP)
Digit 17 = Monitoring Cards
0 = No card, IntelliSlot only (048 and 060 models only)
U = IS-UNITY-DP card, factory-installed (048 and 060 models only)
B = BACnet, Modbus, SNMP using iCOM board (036 model only)
Digit 18 = Sensors
0 = None
S = Smoke sensor
H = High-temperature sensor
F = Smoke and high-temperature sensor
Digit 19 = Packaging
P = Domestic
C = Wood crate export
Digits 20, 21 = Future use
Digit 22 = Factory Configuration code
A = No SFA’s (Any Alpha letter except S)
S = SFA
Digit 23-25 = Factory Configuration Number
Table 2.2 Model-number Digit Definitions (continued)
2.2 Component Location
The unit component locations are described in the submittal documents included in the Submittal
Drawings on page53.
The following tables list the relevant documents by number and title.
Document Number Title
DPN004808 Evaporator Unit, 3-ton
DPN004179 Evaporator Unit, 4-ton and 5-ton
Table 2.3 Component-location Drawings
Vertiv | Liebert® Mini-Mate™ Installer/User Guide
10
