Vertiv Liebert Mini-Mate MT048 - COMPONENT LOCATION DIAGRAM 4&5 ΤΟΝ EVAPORATOR UNIT

REV : 1
REV DATE : 3/18
DPN004179
Page :1 /1
4&5 TON EVAPORATOR UNIT
Form No.: DPN001040_REV4
COMPONENT LOCATION DIAGRAM
LIEBERT MINI-MATE
VARIABLE CAPACITY
Front of Unit
Front of Unit
1
2
4
3
5
1 Variable Speed Direct Drive Fan with EC Motor
2 Evaporator Coil
3 Humidifier (optional)
4 Electric Box
5 Smoke Sensor (optional)
6 Electric Reheat (optional)
6
