2 NOMENCLATURE AND COMPONENTS
This section describes the model number for Liebert® Mini-Mate units and components.
2.1 Mini-Mate Model-number Nomenclature
The tables below describe each digit of the 25-digitconfigurationnumber. The 14-digit model number
consists of the first 10 digits and last 4 digits of the configuration number.
Table 2.2 below describes each digit of the model number.
Model Number Digits 1 to 10 Model Details
ModelNumber
Digits11to14
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
M T 0 6 0 H E 1 A 0 S H 2 0 D 0 U 0 P 0 0 A # # #
Table 2.1 Mini-Mate 25-digit Configuration Number
Digit and Description
Digits 1 and 2 = Unit Family
MT = Mini-Mate Ceiling System
Digits 3, 4, 5 = Nominal Cooling Capacity
036 = 36kBtuh
048 = 48kBtuh
060 = 60 kBtuh
Digit 6 = Air Direction and Discharge
H = Horizontal air flow
Digit 7 = System type
E = Split-system evaporator
Digit 8 = Fan type
1 = Direct-drive EC motor (variable-speed)
Digit 9 = Supply power
A = 460V / 3ph / 60Hz
B = 575V / 3ph / 60Hz (048 and 060 models only)
C = 208V / 3ph / 60Hz (048 and 060 models only)
D = 230V / 3ph / 60Hz (048 and 060 models only)
P = 208-230/1ph/60Hz (036 model only)
Y = 208-230/3ph/60Hz (036 model only)
Digit 10 = Evaporator Type
0 =Split-system evaporator
Digit 11 = Humidifier
0 = No humidifier
S = Steam-gen canister humidifier
Digit 12 = Display type
H = 9-in. remote display, IntelliSlot-based monitoring (048 and 060 models only)
1 = 9-in. remote display, iCOM-based monitoring (036 model only)
Table 2.2 Model-number Digit Definitions
