Vertiv Liebert Mini-Mate MT048 - COMPONENT LOCATION DIAGRAM 3 ΤΟΝ EVAPORATOR UNIT

REV : 0
REV DATE : 06/18
DPN004808
Page :1 /1
3 TON EVAPORATOR UNIT
Form No.: DPN001040_REV4
COMPONENT LOCATION DIAGRAM
LIEBERT MINI-MATE
VARIABLE CAPACITY
1
2
4
3
5
1 Direct Drive Fan with Variable Speed EC Motor
2 Evaporator Coil
3 Humidifier (optional)
4 Electric Box
5 Smoke Sensor (optional)
6 Electric Reheat (optional)
6
Front of Unit
