REV : 1
REV DATE : 8/18
DPN004840
Page :2 /2
Form No.: DPN001040_REV4
LIEBERT MINI-MATE
VARIABLE CAPACITY
UNIT TO UNIT NETWORK CONNECTIONS
REAR VIEW OF DISPLAY
U2U NETWORKING SWITCH
(FIELD SUPPLIED)
TB3
P71
P72
P74 P64
E5
P
6
7
P
6
6
P
1
1
P
1
2
P
2
1
P
2
0
P
1
3
P
7
P76
P95
P100
P75
2
iCOM
MICROPROCESSOR
AND I/O BOARD
Notes:
1. Refer to DPN004802 for connection points on Liebert Mini-Mate unit.
2. Refer to DPN004803 for general arrangement and field connections.
SITE AND BMS
COMMUNICATION
CONNECTIONS
RS485
ETHERNET
TO / FROM
OTHER
NETWORKED
UNITS
ETHERNET CABLE
(FIELD SUPPLIED)
TO
TERMINALS
13,14 AND 15
DO NOT USE CANBUS
CONNECTORS
ETHERNET CABLE
TWO OR MORE 3 TON UNITS NETWORKED USING SWITCH
Field Supplied Wiring - Unit Networking & Site BMS
Field Supplied Wiring - Individual Display
Factory Supplied Ground Wire
