2.2 Component Location
The unit component locations are described in the submittal documents included in the Submittal
Drawings on page35.
The following tables list the relevant documents by number and title.
Document Number Title
DPN004180 PFDCondensing Unit, 3-, 4-, and 5-ton
Table 2.3 Component-location Drawings
