Remote Distribution Cabinet User Manual | 14
Figure 8 Liebert LDMF
™
, Liebert SiteScan
®
and Liebert IntelliSlot
™
location and connection details
RX15006
Rev. 1
Liebert
IntelliSlot
Bays
Liebert LDMF
Liebert SiteScan
Interface (optional)
Adapter Board Connection
Details. See Drawing LDM13008
for Liebert LDMF. For Current
Plus, see drawing LDM13011
Detail A
See Detail A
See Detail B
DB-9 Connector-Liebert
LDMF/Current Plus
Setup Port Connection
Detail B
