Figure 5.6 Replacing a Bullet Nose Circuit Breaker (List CA)
Load Disconnect Circuit Breakers
Front
Components removed in illustration for clarity only.
Insert these
terminals into
corresponding
sockets on
distribution unit.
Insert these
terminals into
corresponding
sockets on
distribution unit.
Shorter Side
of Breaker
Shorter Side
of Breaker
OFF Position Towards Center
Longer Side
of Breaker
Turn circuit breaker off before installing.
