Vertiv™ NetSure™ 5100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
53
Figure 5.10 Replacing an EIB (Controller Extended Interface Board) Circuit Card
J5-J9
Wire Size Capacity: 16 AWG to 26 AWG.
Wire Strip Length: 0.20 inch.
R
ecommended Torque: 2.2 in-lbs.
Optional EIB Assembly
(582137100 List 70)
Optional EIB Assembly
(582137100 List 70)
(exploded view)
Switch settings must be in this position
to interface with the controller.
J4
SW1
J2
J3
Connector
to Controller
IB2 Temp
Probe 2
IB2 Temp
Probe 1
J5 J6 J7 J8 J9
2
4
6
31 5
2
4
6
31 5
2
4
6
31 5
2
4
6
31 5
2
4
6
31 5
-
+
Shunt
Inputs
V
oltage
Inputs
Voltage Inputs Relays
Sh1
V1
V2
V3 V5 V7 V8
V4 V6
RLY11RLY9
Sh2 Sh3
Sh1 Sh2 Sh3
NOCNC NOCNC NOCNC
NOCNC NOCNC
Relays
RLY13 RLY10 RLY12
Terminal Blocks
ON OFF
1 2
Optional EIB
(Controller Extended Interface Board)
