Figure 2: Power Only Bay
Bay LED (Located on outside of front door)
Green = OK
Red = Bay Failure
Front Door Removed in
Illustration for Clarity
Power
Rectifiers
(See Detail B)
System Monitoring and Control
See Detail C or Detail D
