Vertiv | NetSure8200 Series -48 VDC Power System User Manual (UM582140000) | Rev. A
16
Figure 3:
Distribution Only Bay (List 116)
Bay LED
Green = OK
Red = Bay Failure
Distribution
Bus #2
Monitoring
Bus #2 Monitoring
Circuit Card
(See Detail A)*
(behind hinged panel)
* Spare Fuseholders
are located behind
hinged panel
Distribution Bus LED
Green = OK
Red = Distribution Bus Failure
Distribution
Bus #4
Distribution
Bus #1
Distribution
Bus #3
Monitoring
Bus #3 Monitoring
Circuit Card
(See Detail A)*
(behind hinged panel)
Monitoring
Bus #4 Monitoring
Circuit Card
(See Detail A)*
(behind hinged panel)
Optional List C
Bullet Nose
Device Panel
(not to scale)
Front View
Distribution Bay
Monitoring
Bus #1 Monitoring
Circuit Card
(See Detail A)*
(behind hinged panel)
Monitoring and Control Section
See Detail E
Front Door Removed in
Illustration for Clarity
