Figure 1.2 Air flow of the rack-mounted VRC indoor unit
Item Description
1 Space inside cabinet
2 Front of VRC
3 Rear of VRC
4 Heat-rejection air out
5 Hot air from cabinet in
6 Cool air from VRC out
Vertiv™ | VRC Installer/User Guide
4
