Vespa GT 200 User Manual

162
- Remove the camshaft.
- Remove the rocker pin by pushing it through
from the flywheel side.
- Remove the rockers, together with their spring
washers.
Note: Mark the position of the rockers in order to
prevent the reversal of the inlet and outlet rockers
on reassembly.
10.10.13 Removing the Cylinder Head
- Remove the spark plug.
- Remove the two screw fasteners on the outside
of the cylinder head, shown in the figure.
- Loosen the four cylinder head securing nuts in
two or three stages, following a diagonal
crosswise sequence.
- Remove the cylinder head, the two locating
dowels and the cylinder head gasket.
Note: If necessary, the cylinder head can be
removed as a complete assembly, together with
camshaft, rocker pin and camshaft support.
Furthermore, the cylinder head can be removed
without completely removing the timing chain,
together with the tensioner.

Vespa GT 200 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	198 cc
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Capacity	9 liters
Rear Brake	Drum
Seat Height	790 mm
Dry Weight	148 kg
Cooling System	Liquid cooled
Front Suspension	Single arm with coil spring and shock absorber
Front Brake	220 mm disc
Length	1, 930 mm
Height	1170 mm
