Vespa GTS Super 300 ie 2008 User Manual

- Top up if the fluid level is near or below the MIN
level edge. The liquid level must always be be-
tween the MIN and MAX level.
-The coolant consists of an ethylene glycol and
corrosion inhibitor based 50% de-ionised water-
antifreeze solution mix.
CAUTION
DO NOT EXCEED THE MAX. LEVEL WHEN FILLING SO AS
TO AVOID THE COOLANT ESCAPING FROM THE EXPAN-
SION TANK WHEN THE vehicle IS IN USE.
Braking system
Level check
The brake fluid tanks for the front and rear brakes
are located on the pumps under the handlebar
cover. Proceed as follows:
- Remove the brake pump cover
- Rest the vehicle on its centre stand with the han-
dlebars perfectly horizontal;
- Check the fluid level through the sight glass as
shown in the figure. A certain lowering of the level
is caused by wear on the pads.
Vespa GTS Super 300 ie (2008) Maintenance
MAIN - 53
