TYRES
Front tyre Tubeless, 110/70 - 11'' 45L
Rear tyre Tubeless, 120/70 - 10'' 54L
02_04
02_05
Shock absorbers adjustment (02_04, 02_05)
The preloading of the spring can be adjusted to 4 positions using the ring nut located
in the lower part of the shock absorbers and the specific spanner supplied.
Position 1: minimum preload: rider only
Position 2 medium preloading: rider only
Position 3 medium preloading: rider and passenger
Position 4: maximum preloading: rider, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
Spring preloading increases by turning the ring nut towards «A», but decreases if the
ring nut is turned towards «B».
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
30
