03_26
- Very carefully release the front handlebar cover from the side tongues, place internal
and on both sides.
- Move the handlebar cover from the front.
CAUTION
PROCEED WITH CAUTION.
DO NOT DAMAGE THE TONGUES OR THEIR SEATS. HANDLE THE PAINTED
AND PLASTIC COMPONENTS CAREFULLY. DO NOT SCRATCH OR DAMAGE
THEM.
HIGH/LOW BEAM LIGHT BULB
- Disconnect, by sliding the electric connector off.
- Remove the rubber protection «C».
03_27
- Turn it anticlockwise, remove the ring nut «D».
- Slide off the bulb «E» and replace it with one of the same electric characteristics.
CAUTION
DO NOT PULL THE ELECTRICAL CABLES WHEN TAKING OUT THE BULB
ELECTRICAL CONNECTOR.
N.B.
IF MISTING IS NOTICED ON THE INSIDE OF THE TAIL LIGHT, CHECK THAT IT
DISAPPEARS AFTER SOME MINUTES OF IGNITION OF THE TAIL LIGHT. IT IS
A COMMON PHENOMENON AND IS ATTRIBUTABLE TO HUMIDITY AND/OR TO
LOW TEMPERATURES; DOES NOT SHOW FAILURE.
63
