Ignition Electronic inductive discharge
ignition, with variable advance and
separate HV coil.
Ignition advance Three-dimensional map managed
by control unit
Spark plug (125 cm³) NGK CR8EB
Electrode gap 0.7 - 0.8 mm
Fuel system Electronic injection with Ø 26 mm
throttle body, single injector.
Fuel Unleaded petrol (95 RON)
Exhaust silencer Absorption-type exhaust muffler
with catalytic converter.
Emissions compliance EURO 3
150 CM³ ENGINE SPECIFICATIONS
Type Single-cylinder, 4-stroke
Engine capacity 154.8 cm³
Bore x stroke 58.0 x 58.6 mm
Max. power 8.7 kW at 7500 rpm
MAX. torque 12 Nm at 5000 rpm
Compression ratio 10.5: 1
Idle speed 1750±50 rpm
Valve clearance (cold engine) intake: 0.08 mm
exhaust: 0.08 mm
81
