04_37
Front direction indicators (04_37)
To replace the front turn signal light bulbs, remove the lens by loosening the set screw
«A», and extract the bulb socket from its housing; carefully push the bulb downwards,
turn it by approx. 30°, and then extract it. For the refitting operations, proceed in the
reverse order.
04_38
Rear optical unit (04_38)
In order to reach the taillight bulb, it is necessary to remove the 2 set screws «D». To
remove the light bulb, press and rotate it by approx. 30° and then extract it. For the
refitting follow the same operations in the reverse order.
WARNING
IF YOU NOTICE ANY MIST DEVELOPING WITHIN THE INTERNAL SURFACE OF
THE HEADLIGHT, THIS IS PERFECTLY NORMAL AND IS SIMPLY DUE TO THE
HIGH LEVEL OF HUMIDITY AND/OR LOW ATMOSPHERIC TEMPERATURE.
THE PHENOMENON WILL RAPIDLY DISAPPEAR ONCE THE HEADLIGHT IS
SWITCHED ON. HOWEVER,
THE PRESENCE OF WATER DROPS MAY INDICATE AN INFILTRATION,
PLEASE CONTACT YOUR LOCAL PIAGGIO SERVICE STATION.
77
