04_39
Rear turn indicators (04_39)
To replace the front turn signal light bulbs, remove the bulb by loosening screw "A",
then extract the bulb socket from its housing; lightly press the bulb and turn it by ap-
prox. 30°, then extract it. For refitting proceed backwards.
04_40
04_41
Number plate light (04_40, 04_41)
To remove the license plate bulb proceed as follows:
- Slide off the bulb holder «A» from its seat by operating from the inside of the license
plate holder.
- Slide off bulb «B».
CAUTION
DO NOT PULL THE ELECTRICAL WIRING TO EXTRACT THE BULB HOLDER.
78
