Refitting the stator
In order to guarantee the correct engine timing pay
attention to the position of the stator, as shown in
the figure.
Flywheel and starting
Removing the starter motor
− Remove the two screws and detach the drive box
from the starter motor.
− With the aid of a hacksaw, abrade the pinion
head ring.
− Using two screwdrivers, detach the cap.
− Remove the retaining ring shown by the arrow in
the figure and remove the pinion components.
WARNING
THE PACKING ON THE MATING SURFACE MUST AL-
WAYS BE REPLACED WITH A NEW ONE, USING «LOC-
TITE».
Engine Vespa PX 125 150 Euro 2
ENG - 54
