Vespa PX 125 150 euro 2 User Manual

− Remove the 2 fasteners for each turn signal light.
Fuel tank
After removing the seat, detach the electrical con-
nection of the fuel level sensor. Remove the 2
remaining fixings to free the fuel tank assembly.
Lift both tanks thus detaching the hoses with the
fuel tap shut to separate the fuel-oil tanks. Remove
the tank filler cap and insert the special tool
through the tube. Proceed by loosening the nut
and the acting upon ring «B» until releasing the oil
tank.
Specific tooling
020321y Carburettor float removing tool
002850y Oil tank spanner
002973y Fuel tap spanner
Remove the tank filler cap and insert the spanner
thus loosening nut «D», hence extract the fuel tap.
Vespa PX 125 150 Euro 2 Chassis
CHAS - 93
