Advice to use the G2-E for a long time
In the case of using the G2-E with the hose and the cable dropping down
please band them with the provided “self-fusion butyl rubber tape”, by
bowing the power cable as shown in the photograph below.
also improve durability of the power cable.
Making an extra space by bowing the power cable reduces the load
connector and the connecting area with the main unit.
Also it is recommended, for the same result, to band the hose and the
cable somewhere on the opposite side of the intermediate connector.
3 sheets of tape are enclosed. You may band another area of these cables
with the remaining 1 piece, taking into consideration the actual work
and/or wiring.
The tape should be prepared by the user if additionally needed. The
provided sheet is made by cutting the following tape to 105 mm in
length each.
<Recommended article>
Self-fusion butyl rubber tape No.15 made by NITTO
[Size: thickness x width x length] 0.5 mm x 19 mm x 10 m
