■Product Specifications
ION/BEAM GUN
Model
：No. G2-E
Ion generation method
：High voltage AC corona discharge
Impressed voltage
：4.5kVAC(P-P) approx.
Input voltage
：24VDC±5%
Power consumption
：100mA (TYP．)
Dimensions
：L148 x H157 x W44(mm)
Weight
：260g
Air consumption
：0.1~0.6MPa
Ozone generation
：0.05ppm or less (Measured at 50mm)
Warning output
：High voltage alarm output stop (Red LED)
Protective function
：Current fuse (0.5 A on the board)
Working ambient
temperature / humidity
Storage temperature/humidity
：5~40˚C 35~65%RH (No dew condensation or freezing)
：0~60˚C 35~85%RH (No dew condensation or freezing)
Distance from target object
：50~300mm (Installation:Indoor, non-hazardous area)
Static electricity removal time
：Refer to the table on the page 5.
Ion balance
：Within±10V (At 0.3MPa and 150mm from the target)
Material
：Casing：Fire retardant polycarbonate and elastomer
：Hook：SUS
：Electrode Needle：Tungsten
Accessories
：Instruction Manual, AC Adapter
AC Adapter No.AD24-ITC
Rated input voltage
：100-240VAC(50/60Hz) 0.4A（TYP.）
Rated output voltage
：24VDC 0.75A
Working ambient
temperature / humidity
：0~40˚C 5~95%RH（No dew condensation or freezing）
Cable length
：DC output cable:2.5m approx. AC input cable:1.8m approx.
Weight
：about 170g
*The measurement values were obtained on the VESSEL measurement environment and conditions,
so error could be induced depending on the operation environment.
Replaceable Parts : Electrode Needle GN-H
Options : Tube-Fitting Nozzle G-7THN / AC Adapter AD24-ITC /
Speed Controller G-7SC G-7DR / Electrode Needle Replacement Screwdriver G-7DR
