04
STOP CHARGING
1. Disconnect the Type 2 plug from the vehicle inlet（Figure 4）.
2. Disconnect the power plug from the outlet（Figure 5）.
3. Replace the charger plug dust cap and store the charger unit in the bag
provided, in a dry place（Figure 6）.
54 6
CHARGING YOUR VEHICLE
Use only on mains power with fault current circuit breaker.
Carefully read this guide together with your vehicle owner’s handbook prior to
charging your electric vehicle.
1.Firmly inser the power plug into the outlet on the wall. （Figure 1）
2.Select the required current by pressing the button continuously, but do not
exceed t he maximum allowable current of the socket（Figure 2）.
3.Inser the Type 2 plug into the inlet on the electric vehicle（Figure 3）.
4.The device stars charging automatically after the LED Light 1 begins to keep
blinking regularly.
1 2 3
Vehicle will
not charge
Charging plug
is not inserted
fully into the
vehicle
Vehicle is not a
state to accept
a charge
1. Perform a visual check of the charging
plug.
2. Remove the charging plug from the
vehicle, then reinsert it into the vehicle,
ensuring it is fully seated into the
vehicle’s receptacle.
Verify vehicle is able to accept charge.
Refer to the vehicle owner’s manual for
charge instructions.
TROUBLESHOOTING
SolutionProblem Possible Cause
Indicator LED’s
not illumninated
No power
to unit
1. Check circuit breaker and other circuit
loads.
2. Try another wall outlet.
3. Ensure mains plug is fully inserted into
the wall outlet.
Portable charger
internal failure
Contact support
