- 8 -
Ⅲ. DIMENSION
Back View
View from right side
Front View
Top View
DIMENSION
MODEL
L(mm)
W(mm)
H1(mm)
H2(mm)
CL-280
310
320
370
480
CL-600
325
365
405
515
