⑤.CHECK THE WATER LEVEL IN THE TANK.
Please double-check the water level. It may be
necessary to feed the water again after a few minutes
of use, as the air in the water pipe has been expelled.
Double-check the water circulation system and seal
the leak if the water level keeps dropping.
(80mm-100mm from the surface)
FLOW ALARM AND OUTPUT PORTS
In order to ensure that the equipment will not be damaged when the
cooling water circulation is out of control, the CW-3000/3000Pro series
chillers have low flow alarm protection.
1. FLOW ALARM OUTPUT PORT AND WIRING DIAGRAM
2. THE CAUSE OF THE FLOW ALARM AND THE WORKING
STATUS OF THE CIRCULATING COOLING WATER
