VEVOR EM2423 - Product Instruction; Transmitter Components

3
5
6
4
1
2
Figure 1
Transmitter
1. Black alligator clip
Used to connect to the earth or ground.
2. Red alligator clip
Used to connect to the wire to be tracked.
3. Transmit signal adjustment knob
Used to adjust the strength of the transmit signal.
4. Power indicator LED
- 4 -
