3. Power indicator LED
4. "
" Button
Press and hold this button to turn on or off the receiver.
When the receiver is on, briefly press this button to turnon or off
the illumination lamp.
5. Signal strength indicator LEDs
The higher the signal strength detected, the more the red indicator
LEDs light up.
6. Probe
The signal sensing/detecting part of the receiver.
7. Sensitivity adjustment knob
Used to adjust the sensitivity of the receiver.
OPERATION INSTRUCTION
How to Use the Transmitter
1. Connecting the Transmitter
Connect the red alligator clip of the transmitter to the wireyou want
to trace and locate and the black alligator clip tothe earth or ground.
- 6 -
