Warning:
1.
2.
3.
2. Turning on the Transmitter
3. Adjusting Signal Strength
4. Turning off the Transmitter
To turn off the transmitter, press and hold the " " button
for about
2 seconds.
- 8 -
Before connecting the transmitter, ensure that all equipment are
disconnected from the wires to be traced.
To avoid electric shock, before turning on the transmitter, connect
the red alligator clip to the wire you want to trace and the black
alligator clip to the earth or ground.
When the transmitter is on, do not touch any conductor, suchas
metal of the alligator clips, on any wire or cable connectedto the
transmitter.
Press and hold the " " button to turn on the transmitter. The power
indicator LED lights up green to indicate that the transmitter is on.
The red signal indicator LEDs light up in group of three from bottom
to top and follow this cycle, which indicates that the transmitter is
sending signal to the connected wire.
The transmit signal adjustment knob on the top of the transmitter is
used to adjust the intensity of the signal. According to the direction
specified on the transmitter's case, you can increase or decrease
the signal strength manually.
