- 4 -
MODEL AND PARAMETERS
Model
FF-T809
Max. Towing Capacity
5500lbs
Opening And Closing Width
39.4'' Max
Coupler
2''
STRUCTURE DIAGRAM AND COMPONENTS
No.
Name
Qty
1
Coupler(2'')
1
2
Tow Bar
2
3
Reflective Sticker
4
4
Safety Chain(1.2m)
2
5
Bolt (φ12*80mm)
2
6
Bolt (φ12*45mm)
4
7
U-bolt
2
8
U-shaped Connector
2
9
Mounting Bracket
2
10
User Manual
1
1
2
3
4
5
6
7
8
9
