VEVOR JT-5000 - Specifications

- 6 -
Specifications
Model
JT-5000
JT-7000
Max. Load (lbs/kg)
5000/2268
7000/3175
Rated Power
750W
750W
Rated Voltage
AC120V/60Hz
AC120V/60Hz
Rated Current
6.25A
6.25A
Lifting Range
(inch/mm)
5.12-18.5 / 130-470
(Mat)
9.06-22.4 / 230-570
(Column)
6.5-20 / 165-510
（Mat)
10.24-22.4 / 230- 570
（Column)
Ambient
Temperature
- 20°C~70°C
-4°F-~158°F
- 20°C~70°C
-4°F-~158°F
 Be sure to read this manual carefully before using this product.
 Be sure to install, operate, maintain or simply lift the platform according to the
manual, otherwise it may bring safety risks, or even cause property damage,
product damage, injury or death (in rare cases).
 Only authorized personnel can operate or repair the product, and any unofficial
modifications can result in warranty failure and increase the risk of injury or
property damage, so be sure to read and follow the warnings and instructions
on the product label.
SAVE THESE INSTRUCTIONS
