PRODUCT INTRODUCTION
S1
S2
L
+
N
-
110V-220V
load
Wiring（Commecting Mode）
Power supply（Suupply）
PRODUCT INTRODUCTION:
Time range: 0-999 hours/0-999 minutes/0-999 seconds
Display panel size: 79mm*43mm
Installation size: 71mm*40mm*24mm
Features: 18 combinations of time can be set
Relay: Original 20A relay, power < 1800W
Working voltage: DC 12V / DC 24V / AC 110V-220V (optional)
RELAYS ARE AVAILABLE IN 3 OPERATING VOLTAGE SPECIFICATIONS:
DC 12V/DC 24V/AC 110V-220V 2200W
You can choose to buy according to your actual situation, and if you don't know how to wire or
don't know how to choose, you can contact customer service for advice
