- 5 -
M8*10 Expansion Bolts need to be fixed for installation. The groove can
be used for drain water or protect cables. the blind holes in the ramp need
to be drilled through to allow the screw to pass through the ramp and lock
into the ground
STEP 01 Select the dimension
The sizes of the type B curb ramps are listed in parameter table. The load
limit is 15 tons. Please choose the size that matches the ramp .
STEP 02 Align ramp sections
Facing your house, ensure that the ramp sections are in the correct
INSTALLATION STEPS FOR TYPE B(SKU4~SKU9)
order,paying attention to the angle of the ends.
STEP 03 Sighten the screws
M8*10 Expansion Bolts need to be fixed for installation.the blind holes in
the ramp need to be drilled through to allow the screw to pass through the
STEP 04 Tighten the screws
