16
· The maximum allowable voltage between the measuring terminal and the
ground: 600V DC or AC RMS.
· Sampling rate: about 3 times / second
· Automatic shutdown: about 10 minutes.
· 6000 Display: the maximum displayed value is 6000
· Range exceeding indication: "OL" is displayed.
· Battery low voltage indication: when the battery voltage is lower than the normal
working voltage, the " " will be displayed on the LCD.
· Input polarity indication: the "-" symbol is automatically displayed.
· Battery: DC 1.5V AAA ×2。
· Overall dimension:166mm×78mm×64mm
· Weight: about 268g
Accuracy index
Accuracy: ( reading + digit).
Reference conditions: the ambient temperature is 18 ℃ to 28 ℃, and the relative
humidity is not greater than 80%.
AC voltage
Range Resolution Accuracy
60mV 10uV
± (0.8% reading +3 digits)
600mV 100uV
6V 1mV
60V 10mV
600V 100mV
Maximum allowable measurement voltage: 600V (RMS)
Frequency range: 40Hz~1000Hz
